VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141

Latest version V141, work for Landrover Jaguar
Support language:English,French,Germany,Italian,Japanese,Portuguese,Russian,Spanish.

:SP10-F
:
$119.00
:
Buy It Now
VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141
Move your mouse over image or click to enlarge
VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141 VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141 VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141 VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141 VCM2 Professional Diagnostic Scanner VCM II For LandRover Jaguar V141
Buy more related tools and Save more!

Details



                                 VCM II JLR v141 Diagnostic Tool (1)VCM II JLR v141 Diagnostic Tool (2)

                                 VCM II JLR v141 Diagnostic Tool (3)

                               VCM II For F-ord IDS Diagnostic Tool (7)

                                          VCM II For F-ord IDS Diagnostic Tool (8)




VCM II For JLR V141


Support language:

English,French,Germany,Italian,Japanese,Portuguese,Russian,Spanish.
3
1.What does the VCM2 for JLR do?

TheVCM2 for JLR
connects directly to the vehicle OBDII (diagnostic) connector and then to a laptop via a
USB cable for use with SDD.  Once the J2534 DLL filesare loaded, this product will
allow normal operation with the
JLR SDD diagnostic tool.
The device is designed as a replacement pass-through vehicle communications device that can be used for the majority of the JLR SDD diagnostic applications.
Only SCP communications are not possible with this device.


2.How does the VCM2 for JLR operate in J2534 mode?

The VCM2 for JLR device is simple and easy to use.
l Download the latest J2534 DLL software files from the Diagnostic Associates web site www.diagnostic-associates.com/download.htm and install these on the SDD laptop.
l Connect the J2534 device to the vehicle OBDII connector (the device powers from the vehicle).
l Connect the 12ft USB cable to the J2534 device and the other end to the SDD laptop.
l The red vehicle power (PWR) LED will illuminate to show that the device is powered.
l During communication with the vehicle the status (STS) LED will flash green.
l The device interacts with the SDD diagnostic tool in the same way as the existing VCM.


Product Detials:

VCM2 for JLR Overview
u JLR Approved device
u Replacement for JLR SDD VCM
u Covers CAN, & ISO9141 vehicle networks
u Most cost effective for JLR pass-thru


VCI device:

u Best suited for current and future vehicles
u 12ft USB cable as standard included
u Easy to update for J2534 new functionality

1111

Packing List:

VCM2 interface ×1
OBD2 cable ×1
USB cable ×1
CD-DVD x1
Plastic box ×1
